Lösung:
Differenzkurs
Matrize II
266/4
D02
UP
24 TOOL CALL 6 Z S300 ............................................... R3
25 L Z+100 M3
26 CYCL DEF 2.0 GEWINDEBOHREN
27 CYCL DEF 2.1 ABST 2
28 CYCL DEF 2.2 TIEFE -12
29 CYCL DEF 2.3 V.ZEIT 1
30 CYCL DEF 2.4 F300
31 CALL LBL 2
32 L Z+100 R0 F MAX M2
33 LBL 1
34 CYCL DEF 221 MUSTER LINIEN
Q225=+30 ................................................................. START 1. ACHSE
Q226=+42 ................................................................. START 2. ACHSE
Q237=+10 ................................................................. ABSTAND 1. ACHSE
Q238=+8 ................................................................... ABSTAND 2. ACHSE
Q242=5 ..................................................................... ANZAHL SPALTEN
Q243=3 ..................................................................... ANZAHL ZEILEN
Q224=+0 ................................................................... DREHLAGE
Q200=2 ..................................................................... SICHERHEITS-ABSTAND
Q203=-6 ................................................................... KOORDINATE OBERFLAECHE
Q204=20 ................................................................... 2. SICHERHEITS-ABSTAND
35 LBL 0
36 LBL 2
37 CYCL DEF 220 MUSTER KREIS
Q216=+50 ................................................................. MITTE 1. ACHSE
Q217=+50 ................................................................. MITTE 2. ACHSE
Q244=80 ................................................................... TEILKREIS-DURCHMESSER
Q245=+0 ................................................................... STARTWINKEL
Q246=+360 ............................................................... ENDWINKEL
Q247=30 ................................................................... WINKELSCHRITT
Q241=12 ................................................................... ANZAHL
Q200=2 ..................................................................... SICHERHEITS-ABSTAND
Q203=+0 ................................................................... KOORDINATE OBERFLAECHE
Q204=20 ................................................................... 2. SICHERHEITS-ABSTAND
38 LBL 0
39 END PGM 266 MM
