HEIDENHAIN
Differenzkurs
Lösung:
Q6=2 ......................................................................... SICHERHEITS-ABSTAND
Q7=+5 ...................................................................... SICHERE HOEHE
Q8=0 ......................................................................... RUNDUNGSRADIUS
Q9=-1 ....................................................................... DREHSINN
10 CYCL DEF 22.0 RAEUMEN
Q10=5 ....................................................................... ZUSTELL-TIEFE
Q11=100 ................................................................... VORSCHUB TIEFENZUSTELLUNG
Q12=200 ................................................................... VORSCHUB RAEUMEN
Q18=0 ....................................................................... VORRAEUM-WERKZEUG
Q19=150 ................................................................... VORSCHUB PENDELN
11 CYCL DEF 7.0 NULLPUNKT
12 CYCL DEF 7.1 #1
13 CYCL CALL
14 CYCL DEF 7.0 NULLPUNKT
15 CYCL DEF 7.1 #2
16 CYCL CALL
17 CYCL DEF 7.0 NULLPUNKT
18 CYCL DEF 7.1 #3
19 CYCL CALL
20 CYCL DEF 7.0 NULLPUNKT
21 CYCL DEF 7.1 #4
22 CYCL CALL
23 CYCL DEF 7.0 NULLPUNKT
24 CYCL DEF 7.1 #5
25 CYCL CALL
26 CYCL DEF 7.0 NULLPUNKT
27 CYCL DEF 7.1 #6
28 CYCL CALL
29 CYCL DEF 7.0 NULLPUNKT
30 CYCL DEF 7.1 #7
31 CYCL CALL
32 CYCL DEF 7.0 NULLPUNKT
33 CYCL DEF 7.1 #8
34 CYCL CALL
35 L Z+100 R0 F MAX M2
36 LBL 1
37 L X+2,5 Y+32,5 RR
38 FC DR- R8,5 CCX+2,5 CCY+24
39 FC Y+10 DR- R7,5 CCX+12 CCY+13
40 FSELECT 2
41 FC DR- R40 CCY-2
42 FSELECT 2
43 FCT DR+ R10
44 FCT DR- R2 CCX+8 CCY-18
45 FSELECT 1
46 FCT DR+ R8
47 FCT DR- R2 CCX-3 CCY-18
48 FSELECT 2
49 FCT Y+9 DR+ R36
50 FC DR- R6,5 CCX-5,5 CCY+13,5
51 FC X+2,5 Y+32,5 DR- R8,5 CCX+2,5 CCY+24
52 FSELECT 2
53 LBL 0
54 END PGM 276 MM
UP
DEMO-Baum
276/4
C01
Freifahren, Ende
