Anhang
BK3xxx/LC3100 65
KBL - BK 3000
KBL des Buskopplers
kr 2 3 4 5 6 7 8
lsap 2 3 4 5 6 7 8
type MSAZ MSAZ MSAZ_
SI
MSZY MSZY MSZY_
SI
MSZY_
SI
mpsh 0 0 241 0 0 241 241
mpsl 241 241 241 241 241 241 241
mprh 0 0 0 0 0 0 0
mprl 241 241 241 241 241 241 241
scc 0 0 0 0 0 0 0
rcc 1 1 1 0 0 0 0
sac 0 0 1 0 0 1 1
rac 0 0 0 0 0 0 0
fea-
ture_supported
req/con 0x00
0x00
0x00 0x00
0x00
0x00 0x00
0x00
0x10 0x00
0x00
0x00 0x00
0x00
0x00 0x00
0x00
0x10 0x00
0x00
0x10
fea-
ture_supported
ind/res 0x80
0x33
0x06 0x80
0x33
0x06 0x80
0x33
0x06 0x00
0x30
0x00 0x00
0x30
0x00 0x00
0x30
0x00 0x00
0x30
0x00
ci * * * 3000 3000 3000 3000
KBL des FMS-Masters
kr 2 3 4 5 6 7 8
rsap 2 3 4 5 6 7 8
type MSAZ MSAZ MSAZ_
SI
MSZY MSZY MSZY_
SI
MSZY_
SI
mpsh 0 0 0 0 0 0 0
mpsl 241 241 241 241 241 241 241
mprh 0 0 241 0 0 241 241
mprl 241 241 241 241 241 241 241
scc 1 1 1 0 0 0 0
rcc 0 0 0 0 0 0 0
sac 0 0 0 0 0 0 0
rac 0 0 1 0 0 1 1
fea-
ture_supported
req/con 0x80
0x33
0x06 0x80
0x33
0x06 0x80
0x33
0x06 0x00
0x30
0x00 0x00
0x30
0x00 0x00
0x30
0x00 0x00
0x30
0x00
fea-
ture_supported
ind/res 0x00
0x00
0x00 0x00
0x00
0x00 0x00
0x00
0x10 0x00
0x00
0x00 0x00
0x00
0x00 0x00
0x00
0x10 0x00
0x00
0x10
ci * * * 3000 3000 3000 3000
Einstellungen für CP5431 (Verbindungseditor):
kr 2 3
fremder LSAP 2 3
Verbindungsart MSAZ MSAZ
max. PDU-Länge 241 241
Überwachungsintervall * *
Einstellungen für CP5431 (ZI-Editor):
kr 5 6
fremder LSAP 5 6
