Guntermann & Drunck GmbH CATCenter Installation Guide
Page 8
Console Port RJ45 interface on the CATCenter used to connect the UCON
devices.
CPU Port
RJ45 interface on the CATCenter used to connect the
targets.
Network
Ethernet with IP protocol.
Service Port
You can install a firmware update on the CATCenter through
the service port (2.5 mm plug). You will find the CATCenter
service port on the front of the device.
Target
A target is any device that can be operated by a CATCenter.
Transmission RJ45 interface of the UCON products used to connect to the
CATCenter. The transmission interface is connected to a
console port of the CATCenter with a CAT-x cable.
UCON
The UCON devices are used for console connections and
thus provide the user with access to the CATCenter system.
The user can operate and configure via the UCON devices.
Five versions of the UCON device are available (UCON,
UCON-a, UCON-s, UCON-IP-eco and UCON-IP).
