Guntermann & Drunck GmbH CATCenter Installation Guide
Page 42
5.6 UCON-s
Signal type/video analogue video
Video resolution
(depending on cable)
locale connection 1920 x 1440 @ 75 Hz
Transmission length
Workstation module to target module
300 m
Transmission type to workstation module dedicated CAT-x link
Workstations 1
Delay compensation yes
Update process local service socket
Assigned workstation connections at
central module
1
Additional connectable
Workstation computer
2
Power supply Main Type internal power jack
Connection IEC connector (IEC-320 C14)
Voltage AC100-240V/60-50Hz 0.2 - 0.1A
Redundant Type external power pack
(optional) Connection miniDIN-4 power socket
Voltage +12VDC/0,8A
Casing Material anodised aluminium
Dimensions Desktop 270 x 44 x 211 mm (W x H x D)
Rackmount 19” x 1HU x 211 mm (W x H x D)
Weight approx. 1.3 kg
Operating Temperature +5 to +45 °C
environment Air humidity < 80%, not-condensing
Interfaces for workstation SubHD15 socket (Video)
2 x PS/2 socket (Keyboard/Mouse)
2 x USB-A socket (Keyboard/Mouse)
for local workstations computers 2 x RJ45 socket
to central module RJ45 socket
for update 2,5 mm jack
Conformity CE, RoHs
