Guntermann & Drunck GmbH CATCenter Installation Guide
Page 43
5.7 UCON-IP-eco
Signal type/video analogue video
Video resolution locale connection 1920 x 1440 @ 75 Hz
(depending on cable) via IP native 1280 x 1024 @ 75 Hz
Transmission length
Workstation module to target module
300 m
Transmission type to workstation module dedicated CAT-x link
Transmission type to KVM-IP client TCP/IP protocol
Communication Ethernet 10/100 Mbit/s
Workstations 2 (1 x IP; 1 x local; concurrent)
Delay compensation yes
Update process via network
Assigned workstation connections at
central module
1
Power supply Main Type internal power jack
Connection IEC connector (IEC-320 C14)
Voltage AC100-240V/60-50Hz 0.3 - 0.2A
Redundant Type external power pack
(optional) Connection miniDIN-4 power socket
Voltage +12VDC/1,1A
Casing Material anodised aluminium
Dimensions Desktop 435 x 44 x 356 mm (W x H x D)
Rackmount 19” x 1HU x 356 mm (W x H x D)
Weight approx. 3.0 kg
Operating Temperature +5 to +45 °C
environment Air humidity < 80%, not-condensing
Interfaces for workstation SubHD15 socket (Video)
2 x PS/2 socket (Keyboard/Mouse)
to central module RJ45 socket
for network RJ45 socket
for ISDN -
for update via network port
Conformity CE, RoHs
