Guntermann & Drunck GmbH CATCenter Installation Guide
Page 37
5 Technical specifications
5.1 CATCenter X2
Workstation ports per device 2
Workstation ports max. per cluster 16
Transmission type to workstation module dedicated CAT-x link
Target ports 16
Target ports Cascade level 1 128
Target ports Cascade level 2 1024
Transmission type to target module dedicated CAT-x link
Update process local service socket
Network connection no
Power supply Main Type internal power pack
Connection IEC connector (IEC-320 C14)
Voltage AC100-240V/60-50Hz 130 - 80 mA
Redundant Type external power pack
(optional) Connection miniDIN-4 power socket
Voltage +12VDC/1A
Casing Material anodised aluminium
Dimensions Desktop 435 x 44 x 286 mm (W x H x D)
Rackmount 19” x 1HU x 286 mm (W x H x D)
Weight approx. 2.5 kg
Operating Temperature +5 to +45 °C
environment Air humidity < 80%, not-condensing
Interfaces to workstation module RJ45 socket
to target module RJ45 socket
for update 2.5 mm jack
for power switch RJ11 socket
Conformity CE, RoHs
