Steckerbelegung PZF5xx
a c
1 VCC in (+5V) VCC in (+5V)
2 VDD in (+12V) VDD in (+12V)
3
4 /BOOT in DCF_MARK out
5 reserved
6 /P_SEC out P_SEC out
7
8 /P_MIN out P_MIN out
9 /RESET in/out
10 100 kHz out 77,5 kHz out
11 1 MHz out 155 kHz out
12 10 MHz out 310 kHz out
13 SCL
14 SCL_EN
15 SDA
16
17 reserved
18
19 TIME_SYN out
20
21 F_SYNTH out
22 F_SYNTH_OD out
23 F_SYNTH_SIN out
24 COM1 TxD out
25
26 COM0 TxD out
27 reserved
28 reserved
29 COM1 RxD in
30 COM0 RxD in
31
32 GND GND
