Philips S9211/12 - Handbuch (Seite 22)

Preparing the SmartClean system for use
Caution: Do not tilt the SmartClean system to prevent leakage
(Fig. 42).
Note: Hold the SmartClean system while you prepare it for use.
Note: If you clean the shaver in the SmartClean system once a week,
the SmartClean cartridge lasts approximately three months.
1 Put the small plug in the back of the SmartClean system.
2 Put the supply unit in the wall socket.
3 Press the button on the side of the SmartClean system (1) and lift
the top part of the SmartClean system (2) (Fig. 43).
4 Pull the seal off the cleaning cartridge (Fig. 44).
5 Place the cleaning cartridge in the SmartClean system (Fig. 45).
6 Push the top part of the SmartClean system back down (‘click’)
(Fig. 46).
Using the SmartClean system
Caution: Always shake excess water off the shaver before you place
it in the SmartClean system (Fig. 47).
1 Press the top cap to be able to place the shaver in the holder
('click') (Fig. 15).
2 Hold the shaver upside down above the holder. Make sure the
front of the shaver points towards the SmartClean system (Fig. 16).
3 Place the shaver in the holder (1), tilt the shaver backwards (2) and
press down the top cap to connect the shaver ('click') (3) (Fig. 17).
The battery symbol starts to flash, which indicates that the shaver
is charging.
4 Press the on/off button on the SmartClean system to start the
cleaning program (Fig. 48).
During the rinsing phase, the rinsing symbol flashes. When the
rinsing phase is done (after approx. 10 minutes), the rinsing symbol
lights up continuously.
SmartClean system Plus only: After the rinsing phase, the drying
phase starts automatically. During this phase, the drying symbol
English 22
