Guntermann & Drunck GmbH Operating Instructions
CATVision (MC)
6.2.2.18 Signal type input
To ensure the correct display of the transmitted video signal you find selection
in this menu, which type synchronisation signal is available as input video
signal.
The options are:
 Standard: comprises RGB HV, RGsB, RsGsBs
 RGsB/HV: Sync on green and additionally seperated HV
6.2.2.19 Remote sync
Basically, two options are available at the entry „Remote sync“. These are:
 Separated H/V
 as input
When CATVision detects seperated HV signals, the value behind the entry
„Remote sync“ changes to „Separated H/V“. This entry is not editable.
When no seperated HV signals can be detected, you still have the possibilty to
deliver seperated HV signals by choosing the value „Separated H/V“.
With the value „as input“ the signal will be transmitted without any changes from
the PC to the CATVision system.
6.2.3 User Account
Move in the Config Menu to the entry User Account and press Enter . The
following window will open:
User Account CVM
1
USER 01
2 USER 02
3 USER 03
4 USER 04
... bis User 08
OpenAccess
SUPERVISOR
Esc Enter
Here you select the USER ACCOUNT which you want to change.
Move the cursor with the keyboard or mouse to the corresponding account.
page 44
