Guntermann & Drunck GmbH Operating Instructions
CATVision (MC)
page 68
Weight:
CATVision-CPU
CATVision-CON
without USB 1,20 kg without USB 1,10 kg
with USB 1,28 kg with USB 1,18 kg
Power supply:
 Main: 100 – 240 V primary
50 – 60 Hz
 Redundant: DC 12V
5 A
Current consumption (max. values):
at 100 V (Main) at 240 V (Main) at 12 V (red.)
CATVision-CPU 140 mA 82 mA 600 mA
CATVision-CON 240 mA 100 mA 900 mA
Power consumption (max. values):
at 100 V (Main) at 240 V (Main) at 12 V (red.)
CATVision-CPU 9,08 W 9,78 W 7,2 W
CATVision-CON 11,38 W 11,46 W 9,96 W
Heat dissipation (max. values):
at 100 V (Main) at 240 V (Main) at 12 V (red.)
CATVision-CPU 9,08 W 9,78 W 7,2 W
CATVision-CON 11,38 W 11,46 W 9,96 W
Temperature range:
Operation: 5 to 40° C
rel. air moisture < 80%, non precipitate
Storage: - 10 to 55°C, < 85 % Air moisture
