Guntermann & Drunck GmbH Operating Instructions
CATVision (MC)
page 70
Weight:
CATVision-MC2-CPU CATVision-MC2-CON
without USB
1,90 kg without USB 1,35 kg
with USB 1,98 kg with USB 1,43 kg
CATVision-MC3-CPU CATVision-MC3-CON
without USB
2,10 kg without USB 2,00 kg
with USB 2,18 kg with USB 2,08 kg
CATVision-MC4-CPU CATVision-MC4-CON
without USB
2,15 kg without USB 2,00 kg
with USB 2,23 kg with USB 2,08 kg
Power supply:
 Main: 100 – 240 V primary
50 – 60 Hz
 Redundant: DC 12V
5 A
Current consumption (max. values):
at 100 V (Main) at 240 V (Main) at 12 V (red.)
CATVision-MC-CPU 410 mA 200 mA 2 A
CATVision-MC-CON 310 mA 160 mA 1,5 A
Power consumption (max. values):
at 100 V (Main) at 240 V (Main) at 12 V (red.)
CATVision-MC-CPU 26,0 W 26,51 W 21,24 W
CATVision-MC-CON 19,51 W 21,96 W 16,56 W
Heat dissipation (max. values):
at 100 V (Main) at 240 V (Main) at 12 V (red.)
CATVision-MC-CPU 26,0 W 26,51 W 21,24 W
CATVision-MC-CON 19,51 W 21,96 W 16,56 W
Temperature range:
Operation: 5 to 45° C
rel. air moisture < 80%, non precipitate
Storage: - 10 to 55°C, < 85 % Air moisture
