Guntermann & Drunck GmbH Operating Instructions
CATVision (MC)
page 7
2 Scope of Delivery
 Transmitting unit
CATVision-CPU
or
CATVision-MC-CPU
 Receiving unit
CATVision-CON
or
CATVision-MC-CON
 Connecting cable Video/Keyboard/Mouse PS/2
CPU-2
- for connecting the CATVision-CPU:
1 x MDR-20 for monitor, keyboard and mouse port
- for connecting the computer:
1 x PS/2 for mouse port (incl. 9pole adaptor for serial mouse)
1 x PS/2 (incl. AT adaptor) for keyboard port
1 x HD-15 connector for VGA port
and USB Keyboard/ Mouse
USB-AM/BM-2
 Power cable
PowerCable-2
 Transmission cable (order separately)
K-C7-x
 Optional:
-
1 x RS232-M/F-2
-> for connecting a serial terminal device
-
2 x Audio-M/M-2
-> for the audio port
-
K-C7-x
-> for transparent USB 1.1 transmission
 Additional Scope of Delivery for CATVision-MC:
-
VGA-M/M-2
-> HD15 (jack/jack) Video connection cable;
Number depends on existing videochannels
