Guntermann & Drunck GmbH Operating Instructions
CATVision (MC)
page 6
1 Description
The CATVision system consists of a transmitter and a receiver. It allows
operating a console from a distance up to 300 m (max value, dependent on the
resolution and the used cable). Also a local console can be connected to the
transmitter. You can choose between local and remote operation.
If you use a CATVision-MC-System, your PC can be equipped with up to 4
Video-Outlets.
Following products are available (differentiation by existing videochannel/s)
Product Videochannel/s
CATVision 1 videochannel
CATVision-MC2 2 videochannels
CATVision-MC3 3 videochannels
CATVision-MC4 4 videochannels
In general in this manual is spoken of a CATVision-System, since all products
differ in the number of transmittable videochannels.
Exceptions in this manual are:
 Chapter 2 (Scope of delivery),
 Chapter 3 (Installation) und
 Chapter 5.4.4.1 (Change of Videochannel).
The transmission of the monitor, keyboard and mouse signals is done via
CAT-x cable (x = 5, 6, 7). By the possibility of individual video adjustment
different cable qualities and lengths are balanced so that the user is always
getting the optimum picture.
The adjustment of the video signal happens automatically. A manual
adjustment is possible from the remote console via IVT (see
chapter 5.4 ).
Via CAT-x cable the system can also transmit audio and RS232 signals besides
the monitor, keyboard and mouse data. By using an additional CAT-x cable,
USB-signals can be transmitted transparent.
