USB-
section Status --- Is lit, when a CAT-x- connection
betwenn CV-CPU and CV-CON
exist. Is off, when a connection
failure exist.
Power --- Is lit, when the USB-modul is
supplied with voltage by the
CATVision-CON
To (1): A console is active when there are mouse or keyboard activities. Either it
stays active for the time out after the last entry or as long as the
Permanent Access or Protected Mode is active plus the set time out.
Red.
Main
Active
Status
Local CPU Power
ision -CPU
Front view of CATVision-CPU
Main
Active
Status Red.
ision -CON
Remote Power
USB 1.1 Devices Status
Power
Front view of CATVision-CON
