Guntermann & Drunck GmbH Operating Instructions
CATVision (MC)
page 17
5.3 Getting into Operation / LEDs
After having connected the power set switch on the CATVisions via toggle
switch on the rear. The LEDs on the front side mean the following:
CATVision CPU CATVision CON
POWER Redundant is lit when an external power
set is connected and delivers
12V. is lit when an external power set
is connected and delivers 12V.
Main is lit when the main power
supply has been established. is lit when the main power
supply has been established.
Remote Active --- is lit as long as the remote
console is active or can be
active
(1)
. Off when locally
operated
Status ---  Is off when the remote
console is not supplied with
voltage.
 Flashes when there is
voltage but the controller of
the remote console is not
working.
 Is lit steadily when there is
voltage and the controller
works.
Local Active is lit as long as the local
console is active or can be
active
(1)
. Off when operated
locally. Disappear whilst
remote operation
---
Status  Off when the local
console is not supplied
with voltage.
 Flashes when there is
voltage but the controller
of the local console is not
working. (Please contact
our Service personal)
 Is lit steadily when there
is voltage and the
controller is working.
---
CPU Active is lit when one of both
consoles is active.
(1)
---
Status is lit when the emulation of
keyboard and mouse is active ---
