Guntermann & Drunck GmbH
Operating Instructions
CATVision (MC)
page 12
Connection of RS232
Connect the serial device with the
RS232 interface (optional) at
CATVision-CON.
Connection of Audio
Connect the microphone to
Micro In, the speakers and another audio
device (e.g. CD player) to
Line In.
Connection of USB1.1
Connect your USB devices with one of the four available USB-A-ports
on the frontside of the CATVision-CON.
Note: The usage of these USB-interfaces is restricted to a usage
as a transparent USB-transmission to the local PC.
Connection of the transmission cable
Connect the K-C7-x extension cable with the the
USB TRANS (jack)
interface of the receiving unit.
