Enhanced configuration settings
G&D FIBREVision · 41
English
How to change the PLL bandwidth to support image sources that are not DVI
compliant:
Se
tu
p
m
enu
1. Use the terminal emulator to establish a connection to the FIBREVision
system.
2. Use the arrow keys to select the row Special extended options and press Enter .
3. Use the arrow keys to select the row Set PLL bandwidth and press Enter .
4. Optional: If you apply a multichannel variant, use the arrow keys to move the
cursor to the channel whose bandwidth you want to change.
5. Press Space (repeatedly) to select one of the following bandwidths:
 4 MHz (default)
 3 MHz
 6 MHz
 5 MHz
6. Optional: If necessary, repeat steps 3 and 4.
7. Press Q to leave the Set PLL bandwidth menu.
8. Press Q to leave the Special Extended Options menu.
9. Press S to save your settings.
