Monitoring
G&D FIBREVision · 45
English
The following table lists the different fields as well as the possible states:
Querying the diagnosis functions (GETDIAG)
The GETDIAG command can be used to query different diagnosis information of the
KVM extender.
The following table lists the different fields as well as the possible states:
Field Description Status
FreezingActive active Freeze function YES, NO
LocalVideoInput valid video signal at computer module
(CPU)
OK, FAIL
StatusLocal status of computer module (CPU) OK, FAIL
StatusRemote status of user module (CON) OK, FAIL
USBStatus Mode=“TRANS” status of transparent USB bus OK, FAIL
NOTE: Only KVM extenders with USB 1.1 support monitor the status of the trans-
parent USB bus.
For devices with USB 2.0 support the line
USBStatus Mode="Trans" always displays
FAIL .
Command:
<GETDIAG ReqID=”123”/>
Exemplary answer of the KVM extender:
<DIAG Ver="1" ReqID="123">
<Resolution>1600x1200</Resolution>
<TemperatureLocal>35</TemperatureLocal>
<TemperatureRemote>37</TemperatureRemote>
</STATUS>
Field Description Value
Resolution resolution of the incoming video signal in pix-
els
width × height
TemperatureLocal temperature of computer module
(CPU) in °C
rounded number
TemperatureRemote temperature of user module (CON)
in °C
rounded number
