RIGOL
DS1000Z Benutzerhandbuch XIX
Kurztasten Messungen (One-key Measurement of 24 Parameters) ...... 6-21
Frequenzzähler (Frequency Counter Measurement) ........................... 6-26
Messeinstellungen (Measurement Setting) ........................................ 6-27
Löschen Messungen (To Clear the Measurement) .............................. 6-29
Alle Messwerte (All Measurement) ................................................... 6-30
Statistik Funktion (Statistic Function) ............................................... 6-31
Cursor Messungen (Cursor Measurement) ............................................... 6-32
Manuelle Cursor Messung (Manual Mode) ......................................... 6-33
Nachlauf Cursor (Track Mode) ......................................................... 6-37
Auto Cursor Modus (Auto Mode) ...................................................... 6-39
Kapitel 7 Dekodierung Protokolle...................................................... 7-1
Parallel Dekodierung (Parallel Decoding) .................................................. 7-2
RS232 Dekodierung (Option) (RS232 Decoding) ....................................... 7-5
I2C Dekodierung (Option) (I2C Decoding) .............................................. 7-11
SPI Dekodierung (Option) (SPI Decoding) ............................................... 7-15
Kapitel 8 Referenz Signalform ........................................................... 8-1
Referenz Funktion Aktivieren (To Enable REF Function) ............................. 8-2
Referenz Quelle Wählen (To Select REF Source) ....................................... 8-3
Referenz Anzeige Einstellen (To Adjust REF Waveform Display) .................. 8-3
Referenzsignal Speichern (To Save to Internal Memory) ............................ 8-3
Referenzsignal Farbe (To Set the Color) ................................................... 8-3
Referenzsignal Rücksetzen (To reset the REF waveform) ........................... 8-4
Referenzsignal Exportieren (To Export to Internal or External Memory) ....... 8-4
Referenzsignal Importieren (To Import from Internal or External Memory) .. 8-4
Kapitel 9 Gültigkeitstest (Pass/Fail Test) .......................................... 9-1
Pass/Fail Test Aktivieren (To Enable Pass/Fail Test) ................................... 9-2
Signalquelle Einstellen (To Select Source) ................................................ 9-2
Prüf-Maske Einstellen (Mask Range) ........................................................ 9-2
Ausgabe Modus Testergebnis (Test and Ouput) ........................................ 9-3
Prüf-Maske Speichern (To Save the Test Mask) ......................................... 9-4
Prüf-Maske Laden (To Load the Test Mask) .............................................. 9-4
Kapitel 10 Signalaufzeichnung .................................................... 10-1
Wiedergabe Einstellungen (Playback Setting) .......................................... 10-2
Aufnahme Einstellungen (Record Setting) ............................................... 10-3
Kapitel 11 Displayeinstellungen .................................................. 11-1
