Kapitel 17 Technische Daten RIGOL
DS1000Z Benutzerhandbuch 17-5
Data Bits 5 bits, 6 bits, 7 bits, 8 bits
I2C Trigger
Trigger Condition Start, Restart, Stop, Missing Ack, Address, Data, A&D
Address Bits 7 bits, 8 bits, 10 bits
Address Range 0x0 to 0x7F, 0x0 to 0xFF, 0x0 to 0x3FF
Byte Length 1 to 5
SPI Trigger
Trigger Condition TimeOut, CS
Timeout Value 16 ns to 10 s
Data Bits 4 bit to 32 bit
Data Line Setting H, L, X
Measure
Cursor
Manual
mode
Voltage deviation between cursors (△V)
Time deviation between cursors (△T)
Reciprocal of △T (Hz) (1/△T)
Track mode Voltage and time values of the waveform
point
Auto mode Allow to display cursors during auto
measurement
Auto Measurement Measurements of Maximum, Minimum, Peak-Peak Value,
Top Value, Bottom Value, Amplitude, Average, Mean Square
Root, Overshoot, Pre-shoot, Area, Period Area, Frequency,
Period, Rise Time, Fall Time, Positive Pulse Width, Negative
Pulse Width, Positive Duty Cycle, Negative Duty Cycle,
Delay AB , Delay AB , Phase AB , Phase AB
Number of
Measurements
Display 5 measurements at the same time
Measurement
Range
Screen Region
Measurement
Statistic Average, Max, Min, Standard Deviation, Number of
Measurements
Counter Hardware 6 bits counter (channels are selectable)
Math
