Kapitel 17 Technische Daten RIGOL
DS1000Z Benutzerhandbuch 17-7
Waveform Haversine
Sine Frequency Range 0.1 Hz to 25 MHz
Flatness ±0.5 dB (relative to 1 kHz)
Harmonic Distortion -40 dBc
Stray (Non-Harmonic) -40 dBc
Total Harmonic
Distortion
1%
Signal-to-Noise ration 40 dB
Square/Pulse Frequency Range 0.1 Hz to 15 MHz
Rise/Fall time <15 ns
Overshoot <5%
Duty Cycle 10% to 90%
Duty Cycle
Resolution 1% to 10 ns (select the
greater one)
Minimum Pulse Width 20 ns
Pulse Width
Resolution
10 ns or 5 bits (select the
greater one)
Jitter 500 ps
Triangle Frequency Range 0.1 Hz to 100 kHz
Linearity 1%
Symmetry 0 to 100%
Noise [1] Bandwidth 25 MHz
Internal Generated
waveforms Frequency Range 0.1 Hz to 1 MHz
Arbitrary
Waveforms Frequency Range 0.1 Hz to 10 MHz
Waveform Length 2 to 16k pts
Frequency Accuracy 100 ppm (lower than 10
kHz)
50 ppm (greater than 10
kHz)
Resolution 0.1 Hz or 4 bit, select the
greater one
Amplitude Output Range 20 mVpp to 5 Vpp,
High-resistance
10 mVpp to 2.5 Vpp, 50 Ω
Resolution 100 µV or 3 bit, select the
