10 - 1110

DIGITAL INDUSTRIAL CONTROLLER

english

Input for connection of thermocouples

Terminals 38 and 39

For the following thermocouples, the characteristics are linearised internally:

Type

Thermocouple pair

Measurement range Accuracy

J

Fe - CuNi

-200 to +1200 °C

< ± 0.3 % ± 1 Digit

K

NiCr - Ni

-200 to +1370 °C

< ± 0.3 % ± 1 Digit

T

Cu - CnNi

0 to +400 °C

< ± 0.3 % ± 2 Digit

R

Pt 13Rh - Pt

0 to 1760 °C

< ± 0.3 % ± 1 Digit

S

Pt 10Rh - Pt

0 to 1760 °C

< ± 0.3 % ± 1 Digit

Input impedance:

> 1 M

Comparison point compensation:

internal with integrated NTC thermistor
Comparison point compensation error:

0.5 K ± 1 digit

external with Pt 100 resistance thermometer

Controller input 2

Input for standard signal (voltage) 0 ... 10 V

Terminals 18 and 19

(same technical data as for controller input 1)

Input for standard signal (current) 0 (4) ... 20 mA Terminals 17 and 19
(same technical data as for controller input 1)

Input for frequency-analog signal 5 ... 1000 Hz

Terminals 16 and 19

(same technical data as for controller input 1)

Configurable for:

Feed forward control

Follow-up control (external setpoint)

Ratio control

Cascade control

NOTE

If the displayed values are fluctuating, set the limit frequency of the
digital filter to a lower value in the Inputs menu and check the TE
connection.

NOTE

If the displayed values are fluctuating, set the limit frequency of the
digital filter to a lower value in the Inputs menu and check the TE
connection.
