12 - 1110
DIGITAL INDUSTRIAL CONTROLLER
english
The following output signals are configurable (cf. Sections 5.7 and 6.5.4):
•
2-point PWM signal (PWM: Pulse width modulation)
•
3-point PWM signal
•
3-point step signal
•
3-point step signal with external feedback (position control)
Electrical data of the relay
AC
DC
Max. switched voltage
250 V
300 V
Max. switched current
5A
5A
Max. switched power
1250 VA
100 W at 24V, 30 W at 250V
•
Binary output
Terminals 21 and 22
max. load current:
20 mA
Configurable line of action (not inverted / inverted):
Logical value
Output
not inverted
inverted
0
high resistance
inactive
active
1
17.5 ... 24 V
active
inactive
Configurable functions:
•
Signal:
Alarm has occurred
•
Signal:
Error has occurred
•
Signal:
MANUALmode
Outputs for alarms
2 relays with one potential free changeover contact and internal connected bose
(see connection diagram):
Relay 3
Terminals 1, 2 and 3
Relay 4
Terminals 3, 4 and 5
Configurable alarms:
•
Alarm, absolute
•
Alarm, relative
•
Alarm, ratio
Electrical data of the relay
AC
DC
Max. switched voltage
250 V
300 V
Max. switched current
5A
5A
Max. switched power
1250 VA
100 W at 24V, 30 W at 250V
