Kapitel 13 Speichern und Abrufen RIGOL
DS1000Z Benutzerhandbuch 13-15
Output OFF
Status Display OFF
Src1 Setup
Wave Sine
Output OFF
Frequency 100 kHz
Amplitude 1.000 V
Offset 0.00 V
Start Phase 0.00°
Modulation OFF
Src2 Setup
Wave Sine
Output OFF
Frequency 100 kHz
Amplitude 1.000 V
Offset 0.00 V
Start Phase 0.00°
Modulation OFF
Cursor Setting (Cursor)
Mode OFF
Manual
Cursor Type X
Source CH1
Time Unit s
CurA -4*1µs
CurB 4*1µs
Track
Cursor A CH1
Cursor B CH1
CurA -4*1 µs
CurB 4*1 µs
Storage Setting (Storage)
Storage Type Picture
Utility Function Setting (Utility)
