Kapitel 17 Technische Daten RIGOL
DS1000Z Benutzerhandbuch 17-1
Kapitel 17
Technische Daten
Alle Spezifikationen werden zugesichert, es sei denn sie sind mit “typical” markiert.
Voraussetzung ist, das Oszilloskop war in den letzten 30 Minuten ununterbrochen
und im spezifizierten Umgebungstemperaturbereich eingeschaltet.
Sample
Sample Mode Real-time sample
Real-time Sample
Rate
1 GSa/s (single-channel)
500 MSa/s (dual-channel)
250 MSa/s (four-channel)
Averaging
After both the channels finish N samples at the same time, N
can be 2, 4, 8, 16, 32, 64, 128, 256, 512, 1024.
High Resolution The highest resolution is 12 bit
Peak Detection 4 ns
Memory Depth
Single-channel: Auto, 12k pts, 120k pts, 1.2M pts, 12M pts
and 24M pts (option) are available
Dual-channel: Auto, 6k pts, 60k pts, 600k pts, 6M pts and
12M pts (option) are available
Four-channel: Auto, 3k pts, 30k pts, 300k pts, 3M pts and 6M
pts (option) are available
Input
Number of
Channels four-channel
Input Coupling DC, AC or GND
Input Impedance (1 MΩ±2%) || (13 pF±3 pF)
Probe Attenuation
Coefficient 0.01X-1000X, 1-2-5 step
Max Input Voltage
(1MΩ) Maximum input voltage of the analog channel
CAT I 300 Vrms, CAT II 100 Vrms, transient overvoltage
1000 Vpk
