Kapitel 17 Technische Daten RIGOL
DS1000Z Benutzerhandbuch 17-3
DC Offset Accuracy ±0.1 div ± 2 mV ± 1% offset
Channel
to
Channel Isolation
DC to maximum bandwidth: >40 dB
Trigger
Trigger Level
Range ±5 div from the center of the screen
Trigger Mode Auto, Normal, Single
Holdoff Range 16 ns to 10 s
High Frequency
Rejection
[1]
75 kHz
Low Frequency
Rejection
[1]
75 kHz
Trigger
Sensitivity
[1]
1.0div (below 5mV or noise rejection is enabled)
0.3div (above 5mV and noise rejection is disabled)
Edge Trigger
Edge Type Rising, Falling, Rising&Falling
Pulse Trigger
Pulse Condition Positive Pulse Width (greater than, lower than, within
specified interval)
Negative Pulse Width (greater than, lower than, within
specified interval)
Pulse Width Range 8 ns to 10 s
Runt Trigger
Pulse Condition None, > (greater than), < (lower than), <> (within the
specified interval)
Polarity Positive, Negative
Pulse Width Range 8 ns to 4 s
Windows Trigger
Windows Type Rising, Falling, Rising&Falling
Trigger Position Enter, Exit, Time
Windows Time 8 ns to 10 s
Nth Edge Trigger
Edge Type Rising, Falling
Idle Time 16 ns to 10 s
