Lösung:
Fortgeschrittenen-Kurs TNC 4xx
6 Lochkreise parametrisch,
1 Werkzeug, 1 Zyklus
74160/4
C05
17 LBL 10
18 FN 0: Q1 = +50 ......................................................... X-MITTE
19 FN 0: Q2 = +50 ......................................................... Y-MITTE
20 FN 0: Q3 = +20 ......................................................... RADIUS
21 FN 0: Q4 = +10 ......................................................... ANZAHL
22 FN 0: Q5 = +0 ........................................................... STARTWINKEL
23 CALL LBL 1 .............................................................. 1. LOCHKREIS
24 FN 0: Q3 = +30
25 CALL LBL 1 .............................................................. 2. LOCHKREIS
26 FN 0: Q1 = +15
27 FN 0: Q2 = +15
28 FN 0: Q3 = +10
29 FN 0: Q4 = +8
30 CALL LBL 1 .............................................................. 3. LOCHKREIS
31 FN 0: Q1 = +85
32 CALL LBL 1 .............................................................. 4. LOCHKREIS
33 FN 0: Q2 = +85
34 CALL LBL 1 .............................................................. 5. LOCHKREIS
35 FN 0: Q1 = +15
36 CALL LBL 1 .............................................................. 6. LOCHKREIS
37 LBL 0
38 LBL 1 ........................................................................ BEARBEITUNG
39 FN 0: Q25 = +Q5
40 FN 0: Q24 = +1
41 CC X+Q1 Y+Q2
42 FN 4: Q26 = +360 DIV +Q4
43 LP PR+Q3 PA+Q5 R0
44 L Z+Q6 M99
45 LBL 2
46 FN 1: Q25 = +Q25 + +Q26
47 FN 1: Q24 = +Q24 + +1
48 LP PR+Q3 PA+Q25 M99
49 FN 12: IF +Q24 LT +Q4 GOTO LBL 2
50 LBL 0
51 END PGM 74160 MM
UP, DER LOCHKREIS
SELBST
UP, LOCHKREIS
GEOMETRIE
