Lösung:
Fortgeschrittenen-Kurs TNC 4xx
Regelmäßige Lochfläche
7109/5
C01
UP1, Bohrbild
33 LBL 1 ........................................................................ BOHRBILD
34 L X+5 Y+20 R0 F9999 M3 ........................................ VORPOSITION
35 L Z+2 R0 M8
36 LBL 2
37 L IX+10 M99 ............................................................ QUER-SCHRITT
38 LBL 3
39 L IY+8 M99 ............................................................... Y-SCHRITT AUFWAERTS
40 CALL LBL 3 REP 7/7 .................................................. SPALTE AUFWAERTS
41 L IX+10 M99 ............................................................ QUER-SCHRITT
42 LBL 4
43 L IY-8 M99 ................................................................ Y-SCHRITT ABWAERTS
44 CALL LBL 4 REP 7/7 .................................................. SPALTE ABWAERTS
45 CALL LBL 2 REP 3/3 .................................................. RESTLICHE SPALTEN
46 LBL 0
47 END PGM 7109 MM
