Lösung:
Fortgeschrittenen-Kurs TNC 4xx
Mengenlehre innen mit Q-Parametern
761541/4
C01
19 LBL 10
20 L Z+20 R0 F9999 M3
21 CYCL DEF 14.0 KONTUR
22 CYCL DEF 14.1 KONTURLABEL 1 /2
23 FN 0: Q5 = +0 .......................................................... OBERFLAECHE
24 L X+10 Y+25 R0 F9998 M99
25 CYCL DEF 14.0 KONTUR
26 CYCL DEF 14.1 KONTURLABEL 1 /2 /3
27 FN 0: Q5 = -8 ........................................................... OBERFLAECHE
28 CYCL CALL
29 CYCL DEF 14.0 KONTUR
30 CYCL DEF 14.1 KONTURLABEL 2 /3
31 FN 0: Q5 = -16 ......................................................... OBERFLAECHE
32 FN 0: Q6 = -10 ......................................................... ABSTAND
33 CYCL CALL
34 LBL 0
35 LBL 1
36 L X+5 Y+20 RR
37 L Y+75
38 L X+60
39 L Y+20
40 L X+5
41 LBL 0
42 LBL 2
43 CC X+60 Y+55
44 LP PR+35 PA+0 RR
45 CP DR-
46 LBL 0
47 LBL 3
48 L X+55 Y+30 RL
49 L X+25
50 CT Y+50
51 L X+55
52 CT Y+30
53 LBL 0
54 END PGM 761541 MM
UP1,
Rechteck-Tasche
UP2, Kreis-Tasche
UP3, Insel
UP10
