HEIDENHAIN
HEIDENHAIN
Fortgeschrittenen-Kurs TNC 4xx
Mehrfache Verwendung der selben Insel-Kontur
7177/4
C05
UP10, TASCHE
15 LBL 10
16 L X-5 Y-5 RR
17 L X-5 Y+85
18 L X+105 Y+85
19 L X+105 Y-5
20 L X-5 Y-5
21 LBL 0
22 LBL 1
23 L X+0 Y+0 RL
24 L X+18 Y+20
25 L X+18 Y+0
26 L X+0 Y+0
27 CYCL DEF 7.0 NULLPUNKT .................................... ALLES RUECKSETZEN
28 CYCL DEF 7.1 X+0
29 CYCL DEF 7.2 Y+0
30 CYCL DEF 10.0 DREHUNG
31 CYCL DEF 10.1 ROT+0
32 CYCL DEF 11.0 MASSFAKTOR
33 CYCL DEF 11.1 SCL1
34 CYCL DEF 8.0 SPIEGELN
35 CYCL DEF 8.1
36 LBL 0
37 LBL 2
38 CYCL DEF 7.0 NULLPUNKT
39 CYCL DEF 7.1 X+10
40 CYCL DEF 7.2 Y+10
41 CALL LBL 1
42 LBL 0
43 LBL 3
44 CYCL DEF 7.0 NULLPUNKT
45 CYCL DEF 7.1 X+45
46 CYCL DEF 7.2 Y+5
47 CYCL DEF 11.0 MASSFAKTOR
48 CYCL DEF 11.1 SCL1,5
49 CALL LBL 1
50 LBL 0
51 LBL 4
52 CYCL DEF 7.0 NULLPUNKT
53 CYCL DEF 7.1 X+60
54 CYCL DEF 7.2 Y+45
55 CYCL DEF 10.0 DREHUNG
56 CYCL DEF 10.1 ROT+15
57 CALL LBL 1
58 LBL 0
59 LBL 5
60 CYCL DEF 7.0 NULLPUNKT
61 CYCL DEF 7.1 X+35
62 CYCL DEF 7.2 Y+55
63 CYCL DEF 8.0 SPIEGELN
64 CYCL DEF 8.1 X
65 CALL LBL 1
66 LBL 0
67 END PGM 7177 MM
UP1, ORIGINAL
