Lösung:
Fortgeschrittenen-Kurs TNC 4xx
Mengenlehre innen und außen mit Q-Parametern
761591/3
C01
Innenelemente
Außenelemente
20 TOOL DEF 3 L+0 R+1
21 TOOL CALL 3 Z S4000
22 CALL LBL 10
23 L Z+50 R0 F9998 M2
24 LBL 10
25 CYCL DEF 14.0 KONTUR
26 CYCL DEF 14.1 KONTURLABEL 1 /2
27 FN 0: Q1 = -8 ........................................................... TIEFE
28 FN 0: Q3 = +0,4 ........................................................ AUFMASS SEITE
29 FN 0: Q5 = +0 ........................................................... OBERFLAECHE
30 FN 0: Q6 = -2 ........................................................... SICHERHEIT
31 CYCL CALL M3
32 CYCL DEF 14.0 KONTUR
33 CYCL DEF 14.1 KONTURLABEL 1 /2 /3
34 FN 0: Q5 = -8 ........................................................... OBERFLAECHE
35 CYCL CALL
36 CYCL DEF 14.0 KONTUR
37 CYCL DEF 14.1 KONTURLABEL 2 /3
38 FN 0: Q5 = -16 .......................................................... OBERFLAECHE
39 FN 0: Q1 = -10 .......................................................... ABSTAND
40 CYCL CALL
41 LBL 0
42 LBL 1
43 L X+5 Y+20 RR
44 L Y+75
45 L X+60
46 L Y+20
47 L X+5
48 LBL 0
49 LBL 2
50 CC X+60 Y+55
51 LP PR+35 PA+0 RR
52 CP DR-
53 LBL 0
54 LBL 3
55 L X+55 Y+30 RL
56 L X+25
57 CT Y+50
58 L X+55
59 CT Y+30
60 LBL 0
61 LBL 4
62 L X-12 Y+0 RR
63 L Y+105
64 L X+110
65 L Y+0
66 L X-12
67 LBL 0
68 LBL 5
69 L X+0 Y+15 RL
70 L Y+80
71 L X+55
72 L Y+15
73 L X+0
74 LBL 0
75 LBL 6
76 CC X+60 Y+55
77 LP PR+40 PA+0 RL
78 CP DR-
79 LBL 0
80 END PGM 761591 MM
