Lösung:
Fortgeschrittenen-Kurs TNC 4xx
6 Lochkreise parametrisch,
3 Werkzeuge, 3 Zyklen
74161/4
C01
36 LBL 10
37 FN 0: Q1 = +50 ......................................................... X-MITTE
38 FN 0: Q2 = +50 ......................................................... Y-MITTE
39 FN 0: Q3 = +20 ......................................................... RADIUS
40 FN 0: Q4 = +10 ......................................................... ANZAHL
41 FN 0: Q5 = +0 ........................................................... STARTWINKEL
42 CALL LBL 1
43 FN 0: Q3 = +30
44 CALL LBL 1
45 FN 0: Q1 = +15
46 FN 0: Q2 = +15
47 FN 0: Q3 = +10
48 FN 0: Q4 = +8
49 CALL LBL 1
50 FN 0: Q1 = +85
51 CALL LBL 1
52 FN 0: Q2 = +85
53 CALL LBL 1
54 FN 0: Q1 = +15
55 CALL LBL 1
56 L Z+50 R0 F MAX M5
57 LBL 0
58 LBL 1
59 FN 0: Q25 = +Q5
60 FN 0: Q24 = +1
61 CC X+Q1 Y+Q2
62 FN 4: Q26 = +360 DIV +Q4
63 LP PR+Q3 PA+Q5 R0
64 L Z+Q6 M99
65 LBL 2
66 FN 1: Q25 = +Q25 + +Q26
67 FN 1: Q24 = +Q24 + +1
68 LP PR+Q3 PA+Q25 M99
69 FN 12: IF +Q24 LT +Q4 GOTO LBL 2
70 LBL 0
71 END PGM 74161 MM
Individuelle Maße der
Lochkreise
Lochkreise
