Lösung:
Fortgeschrittenen-Kurs TNC 4xx
Regelmäßige Lochfläche mit Q-Parametern
746910/4
C01
Schleifenbeginn
Rücksprung
UP
24 LBL 1 ........................................................................ VORBEREITUNGEN
25 FN 0: Q21 = +Q1 ...................................................... X
26 FN 0: Q22 = +Q2 ...................................................... Y
27 FN 0: Q25 = +0 ......................................................... SPALTE
28 FN 0: Q26 = +0 ......................................................... ZEILE
29 FN 0: Q23 = +Q3 ...................................................... X-SCHRITT
30 LBL 2
31 L X+Q21 Y+Q22 R0 F9999 ....................................... POSITIONIEREN
32 L Z+Q7 R0 F9999 M99 ............................................. BOHREN
33 FN 1: Q21 = +Q21 + +Q23 ....................................... X-SCHRITT
34 FN 1: Q25 = +Q25 + +1 ............................................ SPALTE
35 FN 12: IF +Q25 LT +Q5 GOTO LBL 2
36 FN 0: Q25 = +0 ......................................................... SPALTENZAEHLER
37 FN 1: Q26 = +Q26 + +1 ............................................ ZEILE
38 FN 0: Q23 = -Q23 ..................................................... X-RICHTUNG UMDREHEN
39 FN 1: Q21 = +Q21 + +Q23 ....................................... KOMPENSATION
40 FN 1: Q22 = +Q22 + +Q4 ......................................... Y-SCHRITT
41 FN 12: IF +Q26 LT +Q6 GOTO LBL 2 ...................... UNFERTIG?
42 LBL 0
43 END PGM 746910 MM
