Lösung:
Fortgeschrittenen-Kurs TNC 4xx
6 Lochkreise parametrisch,
3 Werkzeuge, 3 Zyklen
74161/3
C01
0 BEGIN PGM 74161 MM
1 ................................................................................. 6 LOCHKR. M. 3 WZ U. 3 ZYKLEN
2 BLK FORM 0.1 Z X+0 Y+0 Z-22
3 BLK FORM 0.2 X+100 Y+100 Z+0
4 TOOL DEF 1 L+0 R+3,5
5 TOOL CALL 1 Z S1000
6 FN 0: Q6 = +2 ........................................................... ABSTAND
7 FN 0: Q7 = +2 ........................................................... TIEFE
8 FN 0: Q8 = +2 ........................................................... ZUSTELLUNG
9 L Z+10 R0 F9999 M3
10 CYCL DEF 1.0 TIEFBOHREN
11 CYCL DEF 1.1 ABST -Q6
12 CYCL DEF 1.2 TIEFE -Q7
13 CYCL DEF 1.3 ZUSTLG -Q8
14 CYCL DEF 1.4 V.ZEIT 0
15 CYCL DEF 1.5 F100
16 CALL LBL 10
17 STOP M6
18 TOOL DEF 2 L+0 R+2,5
19 TOOL CALL 2 Z S3150
20 FN 0: Q7 = +20
21 FN 0: Q8 = +10
22 L Z+10 R0 F MAX M3
23 CALL LBL 10
24 STOP M6
25 TOOL DEF 3 L+0 R+3
26 TOOL CALL 3 Z S400
27 FN 0: Q6 = +5 ........................................................... ABSTAND
28 CYCL DEF 2.0 GEWINDEBOHREN
29 CYCL DEF 2.1 ABST -Q6
30 CYCL DEF 2.2 TIEFE -15
31 CYCL DEF 2.3 V.ZEIT 0
32 CYCL DEF 2.4 F400
33 L Z+10 R0 F MAX M3
34 CALL LBL 10
35 L M30
Zentrieren
Bohren
Gewinden
