Lösung:
Fortgeschrittenen-Kurs TNC 4xx
Kegelstumpf stehend, 3D vertikal,
Innenform mit Schaftfräser, aufwärts,
mit Schruppen
7284/3
C09
UP, PROFIL
HAUPTPROGRAMM
0 BEGIN PGM 7284 MM
1 ................................................................................. STEHENDER KEGELSTUMPF 3D
2 ................................................................................. VERTIKAL, INNENFORM
3 ................................................................................. AUS DEM VOLLEN MIT
4 ................................................................................. SCHAFTFRAESER
5 BLK FORM 0.1 Z X+0 Y+10 Z-32
6 BLK FORM 0.2 X+100 Y+90 Z+0
7 TOOL DEF 1 L+0 R+10
8 TOOL CALL 1 Z S2800
9 L Z+20 R0 F9999 M3
10 FN 0: Q1 = +20 ......................................................... TIEFE
11 FN 0: Q2 = +35 ......................................................... RADIUS
12 CYCL DEF 5.0 KREISTASCHE
13 CYCL DEF 5.1 ABST -2
14 CYCL DEF 5.2 TIEFE -Q1
15 CYCL DEF 5.3 ZUSTLG -5 F150
16 CYCL DEF 5.4 RADIUS Q2
17 CYCL DEF 5.5 F500 DR+
18 L X+50 Y+50
19 L Z+2 M99 ................................................................ SCHRUPPEN
20 FN 0: Q1 = +10
21 FN 0: Q2 = +15
22 L Z-18 M99
23 CYCL DEF 7.0 NULLPUNKT
24 CYCL DEF 7.1 X+50
25 CYCL DEF 7.2 Y+50
26 FN 1: Q3 = +15 + -Q108 .......................................... XA UNTEN
27 FN 1: Q4 = +35 + -Q108 .......................................... XB OBEN
28 FN 0: Q5 = -25 ......................................................... Z TIEFE 1. SCHNITT
29 CALL LBL 1 .............................................................. SCHRÄGE SCHRUPPEN
30 FN 0: Q5 = -30 ......................................................... Z TIEFE 2.SCHNITT
31 CALL LBL 1 .............................................................. SCHLICHTEN
32 L Z+50 R0 F9999 M2
33 LBL 1
34 L X+Q3 Y+0 Z+Q5 R0 F400 M3 ............................... A
35 L X+Q4 Y+0 Z+0 ...................................................... B
36 LBL 2
37 L X+Q3 Y+0
38 L Z+Q5
39 L X+Q4 Y+0 Z+0 F1000 ........................................... B
40 L X+Q3 F9999 .......................................................... A
41 L Z+Q5 F2000
42 CYCL DEF 10.0 DREHUNG
43 CYCL DEF 10.1 IROT-5
44 CALL LBL 2 REP 71/71
45 CYCL DEF 10.0 DREHUNG
46 CYCL DEF 10.1 ROT+0
47 LBL 0
48 END PGM 7284 MM
