Kapitel 2 Benutzung Ihres Funktionsgenerators
2-100
DG1000Z Benutzerhandbuch
Modulation Source
Int
ASK Rate
100Hz
Modulation Amplitude
2Vpp
ASK Polarity
Pos
FSK Modulation
Modulation Source
Int
FSK Rate
100Hz
Hop Frequency
10kHz
FSK Polarity
Pos
PSK Modulation
Modulation Source
Int
PSK Rate
100Hz
PSK Phase
180°
PSK Polarity
Pos
PWM Modulation
Modulation Source
Int
Modulating Waveform Shape
Sine
Modulation Frequency
100Hz
Width Deviation
200µs
Duty Cycle Deviation
20%
Sweep
Sweep Type
Linear
Sweep Time
1s
Return Time
0s
Start Frequency
100Hz
Stop Frequency
1kHz
Center Frequency
550Hz
Frequency Span
900Hz
Start Hold
0s
Stop Hold
0s
Mark Frequency State
Off
Mark Frequency
550Hz
Trigger Source
Int
Trigger Output
Off
SlopeIn
Leading
Step Number
2
Burst
Burst Mode
N Cycle
Cycle Number
1
Burst Period
10ms
Gated Polarity
Pos
Trigger Source
Int
