Background information
G&D DL-Vision(M/S) · 43
English
Reading out the adjusted IP address
If the IP address of a copmuter module or a user module is unknown, a terminal
emulator (for example HyperTerminal oder PuTTY) can be used to read it out.
Use the supplied service cable tp connect the computer on which the terminal emu-
lator is installed to the Service socket of the computer module and the user module.
How to read out the preset IP address of the device:
1. Turn the device off.
2. Start the terminal emulator.
3. Enter the following conection settings:
 Bits per second: 115.200
 Data bits: 8
 Parity: None
 Stop bits: 1
4. Turn the device on and read the IP address in the terminal emulator.
NOTE: Before establishing a conenction to the terminal emulator, install the
CP210x USB to UART Bridge VCP device driver.
This driver provides the Service socket of the DL-Vision(M/S) system as virtual serial
interface (COM port). The virtual interface can now be selected to establish a con-
nection to the terminal emulator.
The driver can be downloaded at
www.gdsys.de under Downloads > Driver .
