Technical data
56 · G&D DL-Vision(M/S)
Features of the transmission modules
KVM transmission
MULTIMODE TRANSMISSION MODULE
Data transmission
Type:
fibre optics (2 glass fibres)
Interface type:
LC duplex
Cable length (max.)
Multimode 50/125μm, 4700MHz*km, OM4: 400 metres
Multimode 50/125 μm, 2000 MHz*km, OM3: 300 metres
Multimode 50/125 μm, 500 MHz*km, OM2:
82 metres
Multimode 50/125 μm, 400MHz*km:
66 metres
Multimode 62,5/125 μm, 200 MHz*km, OM1: 33 metres
Multimode 62,5/125 μm, 160 MHz*km,
FDDI grade:
26 metres
Performance data
Wave length (
λ
):
850 nm (840 nm to 860 nm)
Optical power output (P
AVG
)
in 50 or 62,5
μ
m MMF:
-7,3 dBm to -1 dBm
Receiving sensitivity (P
MIN
):
-11,1 dBm (OMA)
Sensitivity – Stressed (P
S
):
-7,5 dBm
(OMA, 50
μ
m MMF)
SINGLEMODE TRANSMISSION MODULE
Data transmission
Type:
fibre optics (2 glass fibres)
Interface type:
LC duplex
Cable length (max.)
AR variant
Singlemode 9/125μm, Klasse OS1:
10 kilometres
Wellenlänge (
λ
):
1310 nm
(1260 nm to 1355 nm)
Cable length (max.)
ARU2 variant
Singlemode 9/125μm, Klasse OS1:
2 kilometres
Wave length (
λ
):
1310 nm
(1260 nm to 1360 nm)
Performance data
Optical power output (P
AVG
)
in 9 μm SMF:
-8,2 dBm to +0,5 dBm
Receiving sensitivity (P
MIN
):
-12,6 dBm (OMA)
Sensitivity – Stressed (P
S
):
-10,3 dBm (OMA)
