Configuration
32 · G&D DL-Vision(M/S)
Changing the console video mode
In the standard configuration of the KVM extender, the computer’s image is output at
the monitor of the active console as well as at the monitor of the concurrent console.
You can also define that the image of the other console is deactivated during con-
sole inputs.
The image of the other monitor is reactivated as soon as the user at the concurrent
console finishes his inputs and the time span of the input lock has elapsed.
How to select the video mode for the local console:
How to select the video mode for the remote console:
Related topics:

Changing the time span of the input lock on page 30
 Right for permanent console access on page 31
NOTE: This function can only be (de)activated in the web application.
Conf
ig P
anel
1. Use the tree view to click on KVM Extenders > [All Extenders] .
2. Double-click the computer module of the KVM extender to be configured.
3. Click the Consoles tab.
4. Use the field local > Image display to select between the following options:
 always on
 off for actions at remote console
5. Click OK to save your changes
Confi
g
P
anel
1. Use the tree view to click on KVM Extenders > [All Extenders ] .
2. Double-click the computer module of the KVM extender to be configured.
3. Click the Consoles tab.
4. Use the field remote > Image display to select between the following options:
 always on
 off for actions at local console
5. Click OK to save your changes.
