Status displays
50 · G&D DL-Vision(M/S)
Meaning of the LEDs on the back panels
Range LED Status Meaning
Transmission Link on Communication with remote station has been
established successfully.
blinking No connection to the remote station.
fast
blinking
Crossed cable connection.
Check the cable connection and ensure that the
interfaces with identical designation are con-
nected.
off No communication.
Video on Video data is transmitted.
off No video data available.
Network A|B green on The connection to the network has been
established successfully.
off A connection could not be established.
yellow on The connection to the network has been
established successfully.
blinking Data collision in half duplex mode.
off A connection could not be established.
