Initial configuration of the network settings
16 · G&D DL-Vision(M/S)
8. Use the paragraphs Interface A and/or Interface B to enter the following data:
9. Enter the following data in the field Global network settings:
10.Click OK to save your data.
11.Click the Logout symbol (see figure on the right) to end the active session of
the web application.
12.Remove the twisted pair cable connection between the computer and the com-
puter module or the user module.
13.Integrate the computer module or the user module into the local network.
Operational
mode:
Select the operational mode of interface A or interface B in the
pull-down menu:
 Off: switches off network interface.
 Static: uses static settings.
 DHCP: obtains the settings from a DHCP server.
IP address: Only if the Static operating mode has been selected:
Enter the interface IP address.
Netmask: Only if the Static operating mode has been selected:
Enter the network netmask.
Connection
type:
Select if the network interface and its communication part-
ner are to negotiate the connection type automatically ( Auto )
or if one of the following types is to be applied:
100 Mbit/s full duplex, 100 Mbit/s half duplex, 10 Mbit/s full duplex , or
10 Mbit/s half duplex
Global prefer-
ences:
Select the operational mode in the pull-down menu:
 Static: uses static settings.
 DHCP: obtains the settings from a DHCP server.
Hostname: Enter the device hostname.
Domain: Enter the domain the device is to belong to.
Gateway: Enter the gateway IP address.
DNS Server 1: Enter the DNS server IP address.
DNS Server 2: Optionally, enter the IP address of another DNS server.
In the DHCP operational mode, the following settings are obtained auto-
matically. Inputs are therefore not possible.
