Technical data
G&D DL-Vision(M/S) · 51
English
Technical data
General features
DL-VISION(M/S) SERIES
Graphics Format: DVI-D
Colour depth: 24 Bit
Videobandwidth: max. 300 MP / s
Max. resolution:  2560 × 1600 @ 60Hz
 4096 × 2160 @ 30Hz (UHD-4K)
Examplary resolutions: per video channel:
 2048 × 2048 @ 60Hz
 2048 × 2160 @ 60Hz
 2560 × 1600 @ 60Hz
 3840 × 2160 @ 30Hz (Ultra HD)
when using two video channels
(MC variants only):
 3840 × 2160 @ 60 Hz (Ultra HD)
 4096 × 2160 @ 60 Hz
nVidia 3D-Vision 120Hz:
 1680 × 1050 @ 120Hz
 further standardised resolutions possible
Vertical frequency: 20 Hz to 120 Hz
Horizontal frequency: 25 kHz to 185 kHz
Audio
 AR & ARU2 variants
Transmission type: digital, stereo
Resolution: 24 bit
Sampling rate: 96 kHz
Bandwidth: 22 kHz
USB
 ARU2 variant
Specification: USB 2.0
Transmission type: transparent
Transmission rate: max. 480 Mbit/s, 1,5 Mbit/s, 12 Mbit/s
RS232
 AR & ARU2 variants
Transmission type: transparent
Transmission rate: max. 230.400 bps
Transmitted signals: TxD, RxD, DTR, DSR, RTS, CTS, DCD
Main power supply Type: internal power pack
Connection: IEC plug(IEC-320 C14)
Voltage: AC100-240V/60-50Hz
Redundant
power supply
Type: internal power pack
Connection: IEC plug (IEC-320 C14)
Voltage: AC100-240V/60-50Hz
