Technical data
54 · G&D DL-Vision(M/S)
DL-VISION(M/S)-MC2-AR-CPU | COMPUTER MODULE
Current consumption maximum:
100-240VAC/60-50Hz, 0.7-0.3A
Casing
Material:
anodised aluminium;
nickel-plated steel (bottom)
Dimensions (W × H × D):
435 mm × 1 U × 284,5 mm
Weight:
approx. 3,1 kg
Operating
environment
Temperature:
+5 to +45 °C
Air humidity:
< 80%, non-condensing
DL-VISION(M/S)-MC2-AR-CON | USER MODULE
Current consumption maximum:
100-240VAC/60-50Hz, 0.7-0.3A
Casing
Material:
anodised aluminium;
nickel-plated steel (bottom)
Dimensions (W × H × D):
435 mm × 1 U × 284,5 mm
Weight:
approx. 3,2 kg
Operating
environment
Temperature:
+5 to +45 °C
Air humidity:
< 80%, non-condensing
DL-VISION(M/S)-MC2-ARU2-CPU | COMPUTER MODULE
Current consumption maximum:
100-240VAC/60-50Hz, 0.7-0.3A
Casing
Material:
anodised aluminium;
nickel-plated steel (bottom)
Dimensions (W × H × D):
435 mm × 1 U × 284,5 mm
Weight:
approx. 3,2 kg
Operating
environment
Temperature:
+5 to +45 °C
Air humidity:
< 80%, non-condensing
DL-VISION(M/S)-MC2-ARU2-CON | USER MODULE
Current consumption maximum:
100-240VAC/60-50Hz, 0.9-0.4A
Casing
Material:
anodised aluminium;
nickel-plated steel (bottom)
Dimensions (W × H × D):
435 mm × 1 U × 284,5 mm
Weight:
approx. 3,3 kg
Operating
environment
Temperature:
+5 to +45 °C
Air humidity:
< 80%, non-condensing
