Inbetriebnahme/Konfiguration
4.6.2.2.22 Index 1A04 DPO TxPDO-Map Inputs Ch.3
Index Name Bedeutung Datentyp Flags Default
1A04:0 DPO TxPDO-
Map Inputs Ch.3 PDO Mapping TxPDO 5 UINT8 RO 0x0E (14
dez
)
1A04:01 SubIndex 001 1. PDO Mapping entry (object 0x6020 (DPO Inputs
Ch.3), entry 0x01 (Error Us)) UINT32 RO 0x6020:01, 1
1A04:02 SubIndex 002 2. PDO Mapping entry (object 0x6020 (DPO Inputs
Ch.3), entry 0x02 (Error Up)) UINT32 RO 0x6020:02, 1
1A04:03 SubIndex 003 3. PDO Mapping entry (object 0x6020 (DPO Inputs
Ch.3), entry 0x03 (Warning Us)) UINT32 RO 0x6020:03, 1
1A04:04 SubIndex 004 4. PDO Mapping entry (object 0x6020 (DPO Inputs
Ch.3), entry 0x04 (Warning Up)) UINT32 RO 0x6020:04, 1
1A04:05 SubIndex 005 5. PDO Mapping entry (object 0x6020 (DPO Inputs
Ch.3), entry 0x05 (Status Us)) UINT32 RO 0x6020:05, 1
1A04:06 SubIndex 006 6. PDO Mapping entry (object 0x6020 (DPO Inputs
Ch.3), entry 0x06 (Status Up)) UINT32 RO 0x6020:06, 1
1A04:07 SubIndex 007 7. PDO Mapping entry (object 0x6020 (DPO Inputs
Ch.3), entry 0x07 (Channel Error)) UINT32 RO 0x6020:07, 1
1A04:08 SubIndex 008 8. PDO Mapping entry (object 0x6020 (DPO Inputs
Ch.3), entry 0x08 (Error Sum Current)) UINT32 RO 0x6020:08, 1
1A04:09 SubIndex 009 9. PDO Mapping entry (object 0x6020 (DPO Inputs
Ch.3), entry 0x09 (Warning Sum Current)) UINT32 RO 0x6020:09, 1
1A04:0A SubIndex 010 10. PDO Mapping entry (4 bits align) UINT32 RO 0x0000:00, 5
1A04:0B SubIndex 011 11. PDO Mapping entry (object 0x6020 (DPO Inputs
Ch.3), entry 0x0E (Sync error)) UINT32 RO 0x6020:0F, 1
1A04:0C SubIndex 012 12. PDO Mapping entry (object 0x6020 (DPO Inputs
Ch.3), entry 0x0F (TxPDO State)) UINT32 RO 0x6020:10, 1
1A04:0D SubIndex 013 13. PDO Mapping entry (object 0x6020 (DPO Inputs
Ch.3), entry 0x10 (TxPDO Toggle)) UINT32 RO 0x6020:11, 16
1A04:0E SubIndex 014 14. PDO Mapping entry (object 0x6020 (DPO Inputs
Ch.3), entry 0x11 (Current Us)) UINT32 RO 0x6020:12, 16
4.6.2.2.23 Index 1A05 DPO TxPDO-Map Extended Diag Inputs Ch.3
Index Name Bedeutung Datentyp Flags Default
1A05:0 DPO TxPDO-
Map Extended
Diag Inputs
Ch.3 PDO Mapping TxPDO 6 UINT8 RO 0x04 (4
dez
)
1A05:01 SubIndex 001 1. PDO Mapping entry (object 0x6020 (DPO Inputs
Ch.3), entry 0x13 (Maximum Current Us)) UINT32 RO 0x6020:13, 16
1A05:02 SubIndex 002 2. PDO Mapping entry (object 0x6020 (DPO Inputs
Ch.3), entry 0x14 (Maximum Current Up)) UINT32 RO 0x6020:14, 16
1A05:03 SubIndex 003 3. PDO Mapping entry (object 0x6020 (DPO Inputs
Ch.3), entry 0x15 (Minimum Current Us)) UINT32 RO 0x6020:17, 64
1A05:04 SubIndex 004 4. PDO Mapping entry (object 0x6020 (DPO Inputs
Ch.3), entry 0x16 (Minimum Current Up)) UINT32 RO 0x6020:18, 64
EP9214-0023 und EP9224-0023 88 Version 2.0.0
