Inbetriebnahme/Konfiguration
4.6.2.2.26 Index 1A08 DPO TxPDO-Map Inputs Device
Index Name Bedeutung Datentyp Flags Default
1A08:0 DPO TxPDO-
Map Inputs De-
vice PDO Mapping TxPDO 9 UINT8 RO 0x13 (19
dez
)
1A08:01 SubIndex 001 1. PDO Mapping entry (object 0xF607 (DPO Inputs
Device), entry 0x01 (Temperature Warning)) UINT32 RO 0xF607:01, 1
1A08:02 SubIndex 002 2. PDO Mapping entry (object 0xF607 (DPO Inputs
Device), entry 0x02 (Temperature Error)) UINT32 RO 0xF607:02, 1
1A08:03 SubIndex 003 3. PDO Mapping entry (object 0xF607 (DPO Inputs
Device), entry 0x03 (Us Warning)) UINT32 RO 0xF607:03, 1
1A08:04 SubIndex 004 4. PDO Mapping entry (object 0xF607 (DPO Inputs
Device), entry 0x04 (Us Error)) UINT32 RO 0xF607:04, 1
1A08:05 SubIndex 005 5. PDO Mapping entry (object 0xF607 (DPO Inputs
Device), entry 0x05 (Up Warning)) UINT32 RO 0xF607:05, 1
1A08:06 SubIndex 006 6. PDO Mapping entry (object 0xF607 (DPO Inputs
Device), entry 0x06 (Up Error)) UINT32 RO 0xF607:06, 1
1A08:07 SubIndex 007 7. PDO Mapping entry (object 0xF607 (DPO Inputs
Device), entry 0x07 (Global Error Bit)) UINT32 RO 0xF607:07, 1
1A08:08 SubIndex 008 8. PDO Mapping entry (object 0xF607 (DPO Inputs
Device), entry 0x08 (Sum Current Warning)) UINT32 RO 0xF607:08, 1
1A08:09 SubIndex 009 9. PDO Mapping entry (object 0xF607 (DPO Inputs
Device), entry 0x09 (Sum Current Error)) UINT32 RO 0xF607:09, 1
1A08:0A SubIndex 010 10. PDO Mapping entry (2 bits align) UINT32 RO 0x0000:00, 2
1A08:0B SubIndex 011 11. PDO Mapping entry (object 0xF607 (DPO Inputs
Device), entry 0x0C (Reset Input)) UINT32 RO 0xF607:0C, 1
1A08:0C SubIndex 012 12. PDO Mapping entry (2 bits align) UINT32 RO 0x0000:00, 2
1A08:0D SubIndex 013 13. PDO Mapping entry (object 0xF607 (DPO Inputs
Device), entry 0x0F (TxPDO State)) UINT32 RO 0xF607:0F, 1
1A08:0E SubIndex 014 14. PDO Mapping entry (object 0xF607 (DPO Inputs
Device), entry 0x10 (TxPDO Toggle)) UINT32 RO 0xF607:10, 1
1A08:0F SubIndex 015 15. PDO Mapping entry (object 0xF607 (DPO Inputs
Device), entry 0x11 (Current Us)) UINT32 RO 0xF607:11, 16
1A08:10 SubIndex 016 16. PDO Mapping entry (object 0xF607 (DPO Inputs
Device), entry 0x12 (Current Up)) UINT32 RO 0xF607:12, 16
1A08:11 SubIndex 017 17. PDO Mapping entry (object 0xF607 (DPO Inputs
Device), entry 0x13 (Voltage Us)) UINT32 RO 0xF607:13, 16
1A08:12 SubIndex 018 18. PDO Mapping entry (object 0xF607 (DPO Inputs
Device), entry 0x14 (Voltage Up)) UINT32 RO 0xF607:14, 16
1A08:13 SubIndex 019 19. PDO Mapping entry (object 0xF607 (DPO Inputs
Device), entry 0x15 (Temperature)) UINT32 RO 0xF607:15, 16
4.6.2.2.27 Index 1A09 DPO TxPDO-Map Extended Diag Inputs Device
Index Name Bedeutung Datentyp Flags Default
1A09:0 DPO TxPDO-
Map Extended
Diag Inputs De-
vice PDO Mapping TxPDO 10 UINT8 RO 0x04 (4
dez
)
1A09:01 SubIndex 001 1. PDO Mapping entry (object 0xF607 (DPO Inputs
Device), entry 0x16 (Peak Value 1)) UINT32 RO 0xF607:16, 16
1A09:02 SubIndex 002 2. PDO Mapping entry (object 0xF607 (DPO Inputs
Device), entry 0x17 (Peak Value 2)) UINT32 RO 0xF607:17, 16
1A09:03 SubIndex 003 3. PDO Mapping entry (object 0xF607 (DPO Inputs
Device), entry 0x18 (Timestamp 1)) UINT32 RO 0xF607:18, 64
1A09:04 SubIndex 004 4. PDO Mapping entry (object 0xF607 (DPO Inputs
Device), entry 0x19 (Timestamp 2)) UINT32 RO 0xF607:19, 64
