Inbetriebnahme/Konfiguration
Index 1A01 DIG TxPDO­Map Diag Inputs Ch.2
Index Name Bedeutung Data type Flags Default
1A01:0 DIG TxPDO­Map
Diag Inputs Ch.2 PDO Mapping
TxPDO 2 UINT8 RO 0x09 (9
dez
)
1A01:01 SubIndex 001 1. PDO Mapping
entry (object
0x6010 (DO
Inputs Ch.2),
entry 0x01 (Input
1)) UINT32 RO 0x6011:01, 1
1A01:02 SubIndex 002 2. PDO Mapping
entry (object
0x6010 (DO
Inputs Ch.2),
entry 0x02 (Input
2)) UINT32 RO 0x6011:02, 1
1A01:03 SubIndex 003 3. PDO Mapping
entry (object
0x6010 (DO
Inputs Ch.2),
entry 0x03 (Input
3)) UINT32 RO 0x6011:03, 1
1A01:04 SubIndex 004 4. PDO Mapping
entry (object
0x6010 (DO
Inputs Ch.2),
entry 0x04 (Input
4)) UINT32 RO 0x6011:04, 1
1A01:05 SubIndex 005 5. PDO Mapping
entry (object
0x6010 (DO
Inputs Ch.2),
entry 0x05 (Input
5)) UINT32 RO 0x6011:05, 1
1A01:06 SubIndex 006 6. PDO Mapping
entry (object
0x6010 (DO
Inputs Ch.2),
entry 0x06 (Input
6)) UINT32 RO 0x6011:06, 1
1A01:07 SubIndex 007 7. PDO Mapping
entry (object
0x6010 (DO
Inputs Ch.2),
entry 0x07 (Input
7)) UINT32 RO 0x6011:07, 1
1A01:08 SubIndex 008 8. PDO Mapping
entry (object
0x6010 (DO
Inputs Ch.2),
entry 0x08 (Input
8)) UINT32 RO 0x6011:08, 1
1A01:09 SubIndex 009 9. PDO Mapping
entry (5 bits
align) UINT32 RO 0x0000:00, 8
