Produktübersicht
Abb. 55: EP28170008, DIG Outputs Channel n
Die Zuordnung erfolgt immer paarweise linke und rechte Seite des DSUBSteckverbinders, um
doppeltschaltende Ventile systematisch anzuschließen.
Typ
Output
2
Output
4
Output
6
Output
8
Output
10
Output
12
Output
14
Output
16
Output
18
Output
20
Output
22
Output
24
Pin
14
15
16
17
18
19
20
21
22
23
24
25
Typ
Output
1
Output
3
Output
5
Output
7
Output
9
Output
11
Output
13
Output
15
Output
17
Output
19
Output
21
Output
23
GND
Pin
1
2
3
4
5
6
7
8
9
10
11
12
13
DIG Outputs Device
Unter DIG Outputs Device finden Sie die ControlAusgänge des Moduls.
Abb. 56: EP28170008, DIG Outputs Device
Set safe state
Setzt das Modul in den sicheren Zustand.
Reset outputs
