Inbetriebnahme/Konfiguration
Index 1601 DIG RxPDO­Map OutputsCh.2
Index Name Bedeutung Datentyp Flags Default
1601:0 DIG RxPDO­
Map
OutputsCh.2 PDO Mapping
RxPDO 2 UINT8 RO 0x09 (9
dez
)
1601:01 SubIndex 001 1. PDO Mapping
entry (object
0x7010 (DIG
Outputs Ch.2),
entry 0x01
(Output 1)) UINT32 RO 0x7010:01, 1
1601:02 SubIndex 002 2. PDO Mapping
entry (object
0x7010 (DIG
Outputs Ch.2),
entry 0x02
(Output 2)) UINT32 RO 0x7010:02, 1
1601:03 SubIndex 003 3. PDO Mapping
entry (object
0x7010 (DIG
Outputs Ch.2),
entry 0x03
(Output 3)) UINT32 RO 0x7010:03, 1
1601:04 SubIndex 004 4. PDO Mapping
entry (object
0x7010 (DIG
Outputs Ch.2),
entry 0x04
(Output 4)) UINT32 RO 0x7010:04, 1
1601:05 SubIndex 005 5. PDO Mapping
entry (object
0x7010 (DIG
Outputs Ch.2),
entry 0x05
(Output 5)) UINT32 RO 0x7010:05, 1
1601:06 SubIndex 006 6. PDO Mapping
entry (object
0x7010 (DIG
Outputs Ch.2),
entry 0x06
(Output 6)) UINT32 RO 0x7010:06, 1
1601:07 SubIndex 007 7. PDO Mapping
entry (object
0x7010 (DIG
Outputs Ch.2),
entry 0x07
(Output 7)) UINT32 RO 0x7010:07, 1
1601:08 SubIndex 008 8. PDO Mapping
entry (object
0x7010 (DIG
Outputs Ch.2),
entry 0x08
(Output 8)) UINT32 RO 0x7010:08, 1
1601:09 SubIndex 009 9. PDO Mapping
entry (8 bits
align) UINT32 RO 0x0000:00, 8
