Video profiles
27 · G&D IP-Console Client
The »Video profile« tab
The Video profile tab is divided into two parts:
 Active Profile: displays the profile which is currently applied
 Further Profiles: displays further video profiles which have been created for this target
The following information are displayed for each video profile:
NOTE: The booting phase, the login procedure at the operating system, and the tar-
get’s user interface are often displayed with different monitor resolutions.
In such cases, separate video profiles are displayed due to the different video charac-
teristics.
IMPORTANT: Video profiles of targets that are currently not accessing the system
can also be viewed, edited or deleted.
The upper part of the window always displays the profile of the currently accessing
target. The lower part of the window lists all available video profiles of the selected
targets.
Name: video profile name
Resolution: horizontal and vertical resolution as well as vertical repetition rate of
the video profile
Source: displays by which “source” the profile has been created:
 Auto: video profile has been created during the first access on a target
 C-Auto: video profile has been created during the initial start-up proce-
dure or with the create video profile function
 User: settings and/or the video profile name have been edited by the
user
